Dik Geurts – Odin Tunnel, Fixed

Call for best price

Save
Save

Description

Style and function in perfect harmony

Designed with style, efficiency and ease of use and meticulously crafted. That is the Dik Geurts Odin.
Its distinctive circular design not only makes it a real eye catcher, but its shape also generates fabulous flame patterns. Flames which are easy to control, with just one unique air slider that is exclusive to Dik Geurts.



Specifications

Brand Dik Geurts
Series Odin
Category Wood stoves
EcoDesign Ready Yes
Energy efficiency class A
Product fiche Click for PDF-file
Model Suspended
Fire view Tunnel
Shape Round
Fuel Wood
Combustion system Combustion air from living area
Suitable for passive houses No
Glass window Standard glass
Door type Hinged door

More Specifications

Control Manual control
S-Thermatik NEO No
Colours Dark anthracite
Material Steel
Interior Vermiculite dark anthracite
Output net min. (kW) 6.0
Output net max. (kW) 10.0
Nominal heat output 8.3
Max. log length (cm) 33
Efficiency (%) 75.0
CO emission (%-13% O2) 0.07
Particulate Matter (mg/Nm3-13% O2) 40
OGC/CxHy (mg/Nm3-13% O2) 77
NOx emission (mg/Nm3-13% O2) 127
Built-in depth (mm) 400
Fire view width (mm) 424
Fire view height (mm) 424
Weight (kg) 100
Flue Top
Flue Ø (mm) 150
External air connection Base
Convection connection No
230V necessary No
Approvals EN13240, Flamme Verte, BlmSchV, EcoDesign
Declaration of performance Click for PDF-file
Dimensions Click for PDF-file
Product manual Click for PDF-file



Additional information

Flue outlet

150mm

Fuel

Wood

Material

Steel

Output

6 – 10kw
