Description
Style and function in perfect harmony
Designed with style, efficiency and ease of use and meticulously crafted. That is the Dik Geurts Odin.
Its distinctive circular design not only makes it a real eye catcher, but its shape also generates fabulous flame patterns. Flames which are easy to control, with just one unique air slider that is exclusive to Dik Geurts.
Specifications
| Brand | Dik Geurts |
|---|---|
| Series | Odin |
| Category | Wood stoves |
| EcoDesign Ready | Yes |
| Energy efficiency class | A |
| Product fiche | Click for PDF-file |
| Model | Suspended |
| Fire view | Front |
| Shape | Round |
| Fuel | Wood |
| Combustion system | Combustion air from living area |
| Suitable for passive houses | No |
| Glass window | Standard glass |
| Door type | Hinged door |
More Specifications
| Control | Manual control |
|---|---|
| S-Thermatik NEO | No |
| Colours | Dark anthracite |
| Material | Steel |
| Interior | Vermiculite dark anthracite |
| Output net min. (kW) | 4.0 |
| Output net max. (kW) | 8.0 |
| Nominal heat output | 6.7 |
| Max. log length (cm) | 33 |
| Efficiency (%) | 75.2 |
| CO emission (%-13% O2) | 0.05 |
| Particulate Matter (mg/Nm3-13% O2) | 31 |
| OGC/CxHy (mg/Nm3-13% O2) | 67 |
| NOx emission (mg/Nm3-13% O2) | 140 |
| Built-in depth (mm) | 380 |
| Fire view width (mm) | 424 |
| Fire view height (mm) | 424 |
| Weight (kg) | 100 |
| Flue | Top |
| Flue Ø (mm) | 150 |
| External air connection | Base |
| Convection connection | No |
| 230V necessary | No |
| Approvals | EN13240, Flamme Verte, BlmSchV, Defra, EcoDesign |
| Declaration of performance | Click for PDF-file |
| Dimensions | Click for PDF-file |
| Product manual | Click for PDF-file |
Additional information
| Flue outlet | 150mm |
|---|---|
| Fuel | Wood |
| Material | Steel |
| Output | 6 – 10kw |
