Description
Robust, stylish wood stove
Jannik Medium, Low is a robust and stylish wood stove with a classic yet modern design that can be used as a freestanding woodburner or installed into a converted inglenook chimney opening. It has an attractive dark anthracite finish, a reassuring solid sqaure body shape, a large viewing window and heat outputs from 4 – 7 kW.
Specifications
| Brand | Dik Geurts |
|---|---|
| Series | Jannik |
| Category | Wood stoves |
| EcoDesign Ready | Yes |
| Energy efficiency class | A+ |
| Product fiche | Click for PDF-file |
| Model | Freestanding |
| Fire view | Front |
| Shape | Horizontal |
| Fuel | Wood |
| Combustion system | Combustion air from living area |
| Suitable for passive houses | No |
| Glass window | Standard glass |
| Door type | Hinged door |
More Specifications
| Control | Manual control |
|---|---|
| S-Thermatik NEO | No |
| Colours | Dark anthracite |
| Material | Steel |
| Interior | Vermiculite natural |
| Output net min. (kW) | 4.0 |
| Output net max. (kW) | 7.0 |
| Nominal heat output | 4.9 |
| Max. log length (cm) | 35 |
| Efficiency (%) | 82.0 |
| CO emission (%-13% O2) | 0.09 |
| Particulate Matter (mg/Nm3-13% O2) | 8 |
| OGC/CxHy (mg/Nm3-13% O2) | 62 |
| NOx emission (mg/Nm3-13% O2) | 78 |
| Built-in depth (mm) | 375 |
| Fire view width (mm) | 328 |
| Fire view height (mm) | 268 |
| Weight (kg) | 90 |
| Flue | Top, Rear |
| Flue Ø (mm) | 125/130 |
| External air connection | Base |
| Convection connection | No |
| 230V necessary | No |
| Approvals | EN13240, BlmSchV, Defra, EcoDesign, Hetas |
| Declaration of performance | Click for PDF-file |
| Dimensions | Click for PDF-file |
| Product manual | Click for PDF-file |
Additional information
| Flue outlet | 125mm |
|---|---|
| Fuel | Wood |
| Material | Steel |
| Output | Below 6kw |
